Kaiser, John H.  Lumber Co. #1 - s/n 1965 - Winter, Wisconsin - taken 1909
Built 08/03/1907 - Std gauge - 10" x 12" cylinders - 29½" drivers - 37 tons - 2 trucks

Special photo posting permission granted by :
Minnesota Historical Society   /    Location No. HD5.33 p13  /   Negative No. 5000

Kalbach, Harrison  Lumber Co. #4 - s/n 791 - destined for Richmond Furnace, Pennsylvania
Built 12/06/1902 - 36" gauge - (2) 6" x 10" cylinders - 22"  drivers - 10 tons - 2 trucks - named "Kalbach"

Note the two outward positioned cylinder steam chests with the single cover plate for both.   Unlike the Willamette locomotives whose cylinders were positioned outward,  very few Shays employed this design.

Photo posting permission was granted by the Allen County Historical Society courtesy of Dan Rowe.
Dan also supplied all the information.

Kalbach's railroad here utilized wood rail.  Strap iron was attached to the top on curves and grades.301d

Kalbach, Harrison  & Son #1 - s/n 341 - destined for Lebanon, Pennsylvania
Built 04/21/1891 - 36" gauge - (2) 6" x 10" cylinders -10 tons - 2 trucks -  named "Achilles"

Note the two outward positioned cylinder steam chests with the single cover plate for both.   Unlike the Willamette locomotives whose cylinders were positioned outward,  very few Shays employed this design.

Photo posting permission was granted by the Allen County Historical Society courtesy of Dan Rowe.
Dan also supplied all the information.
Kane & Elk Railroad #104 - s/n 104
Built 02/26
/1884 ~ 36" gauge ~ (2) 8" x 8" cylinders ~ 24" drivers ~ 11 tons ~ 2 trucks

The locomotive, owned by the Kane & Elk Railroad Co., operated near Kane, Pennsylvania.
The photo is part of the Walter Casler collection.

Kane & Elk Railroad #108 - s/n 727
Built 03/18
/1903 - Std gauge - 11" x 12" cylinders - 32" drivers - 40 tons - 2 trucks

The locomotive, owned by the Kane & Elk Railroad Co., operated near Kane, Pennsylvania.
The photo is part of the Walter Casler collection.

Kansas City Southern Railway #900 - s/n 2570 destined for Kansas City, Missouri
Built 02/05/1913 - Std. gauge - 18" x 20" cylinders - 48" drivers - 160 tons (286,700 lbs) - 3 trucks - maximum tractive effort 74,400 lbs.

It was the heaviest Shay that Lima ever built.  It also had the distinction of being the only one built with this cylinder size.

Photo posting permission was granted by the Allen County Historical Society courtesy of Dan Rowe.
Dan also supplied all the information.


Kansas City Southern Railway #901- s/n 2659
Built 02/04/1914 - Std gauge -  17" x 18" cylinders -
48"  drivers - 130 tons - 3 trucks

The company's base of operations was Kansas City, Missouri
This image appeared in the November, 1915 issue of The Locomotive World periodical.

Kaul Lumber Co. #6 - s/n 1617
Built 12/07/1905 - Std gauge - 12" x 12" cylinders - 32" drivers - 55 tons - 2 trucks

The locomotive operated near Kaulton, Alabama
Photo published in Green Gold: Alabama's Forests and Forest Industries    Available >here

Kaul & Hall Lumber Co. #14 - s/n 3062 - destined for Tuscaloosa, Alabama
Built 04/12/1920 - Std. gauge - 12" x 12" cylinders - 32 " drivers - 65 tons - 3 trucks


Kaul & Hall Lumber Co., Inc.  #71 - s/n 530
Built 05/29/1897 ~ Std gauge - 11" x 12" cylinders - 32" drivers - 45 tons - 2 trucks

The locomotive operated near St. Marys, Pennsylvania.  The company previously ran the locomotive with road #23 and subsequently with road #171 at the same location.
The photo is from the Railroad Museum of Pennsylvania ~ General Negative Collection ~ Negative #16084

Kaul & Hall Lumber Co. Inc.  #73 - s/n 748 ~ destined for Saint Marys, Pennsylvania
Built 01/20/1903 ~ Std
gauge ~ 12" x 15" cylinders ~ 33" drivers ~ 65 tons ~ 3 trucks

The photo is from the Allen County Museum collection held by the Ohio History Center ~ ID = Om437_896698_013

Kaul & Hall Lumber Co. Inc. #172 - s/n 577
Built 09/06/1899 ~ Std gauge ~ 13" x 13" cylinders ~ 32" drivers ~ 60 tons ~ 3 trucks

The locomotive operated near Saint Marys, Pennsylvania
The photo is from the
Railroad Museum of Pennsylvania ~ General Negative Collection ~ Negative #16086

Keith & Hiles Lumber Co. #1 - s/n 1659
Built 04/11/1906 - Std. gauge - 11" x 12" cylinders - 32" drivers - 45 tons - 2 trucks


The locomotive, named
Metonga,  operated near Crandon, Wisconsin
Photo hosted by the Crandon Public Library  of Crandon, Wisconsin
Kelley, D. L. Logging Co. #1 - s/n 766 ~ destined for Warrenton, Oregon
Built 03/18/1903 ~ Std
gauge ~ 10" x 10" cylinders ~ 28" drivers ~ 28 tons ~ 2 trucks

The photo is from the Allen County Museum collection held by the Ohio History Center ~ ID = Om437_896698_016

Kelley Island Lime & Transport Co. #2 - s/n 228
Built 02/12/1889 ~ 36"
gauge ~ (2) 9" x 8" cylinders ~ 26" drivers ~ 17 tons ~ 2 trucks

The locomotive operated on
Kelley's Island, Ohio.
The photo is from the Lake Erie's Yesterdays Collection held by the Ohio Digital Resource Commons ~ ID = 797h158b / FR-2
Kelley Island Lime & Transport Co. #3 (2nd) s/n 3112 @ Marblehead, Ohio in 1939
Built 09/25/1920 - Std. gauge - 11" x 12" cylinders  - 32"
drivers - 50 tons - 2 trucks
Of the 66 Shay's owned by the company, this was the only built to a standard gauge.

Photo courtesy of the Marc Reusser collection.
Kelley Island Lime & Transport Co. #11 ~ s/n 706
Built 01/03/1902 ~ 36"
gauge ~ (2)9" x 8" cylinders ~ 26" drivers ~ 17 tons ~ 2 trucks ~ "boot" boiler

The locomotive, named Marion Rees, operated at the company's Kelley Island, Ohio location.
The photo is from the Howard Ameling Collection
Kelley Island Lime & Transport Co. #16 - s/n 787
Built 03/27/1903 - 36" gauge - (2) 9
" x 8" cylinders - 26 drivers - 17 tons - 2 trucks ~ "boot" boiler

The locomotive, named "WM. Chisholm Jr.",  operated near Marblehead, Ohio.

Kelley Island Lime & Transport Co. #17 - s/n 793
Built 04/01/1903 ~ 36" gauge ~ (2) 9"x 8" cylinders ~ 26" drivers ~ 17 tons ~ 2 trucks ~ "boot" boiler

The locomotive, named W. A. Pardee, operated at the company's Kelley Island, Ohio location.
Photo credit: Bob Lorenz collection via The Lakeside and Marblehead Railroad

Kelley Island Lime & Transport Co. #22 - s/n 902 @ Marblehead, Ohio in 1934
Built 07/22/1904 - 36"gauge - (2) 9" x 8" cylinders - 26" drivers - 17 tons - 2  trucks - "boot" boiler

The locomotive was named the "Geo. B. Morley"
Kelley Island Lime & Transport Co. #30 - s/n 1854
Built 05/04/1907 - 36" gauge - (2) 8
" x 12" cylinders - 26½" drivers - 18 tons - 2 trucks

The locomotive, named "Katherine Hoyt", operated on Kelly Island, Ohio
Photo credit: OhioLink

Kelley Island Lime & Transport Co. #31  - s/n 1855 - Marblehead, Ohio
Built 05-03-1907 - 36" gauge - (2) 8" x 12" cylinders - 26½"
drivers - 18 tons - 2 trucks

Named "Mary Sanders"
Kelley Island Lime & Transport Co. #38 ~ s/n 2077
Built 04/01/1908 ~ 36" gauge ~ (2 )8" x 12" cylinders ~ 26½" drivers ~ 20 tons ~ 2 trucks

The locomotive, named "Sarita Oglebay", operated near Sandusky, Ohio
Top photo is from The Kelley Island Lime & Transport Company
Facebook page.
Kelley Island Lime & Transport Co. #53 - s/n 2429 - destined for Marblehead, Ohio
Built 03/22/1911 - 36" gauge - (2) 8" x 12" cylinders - 27½" drivers - 20 tons - 2 trucks

The company name is misspelled in the lettering on the tender on this image of the builder's photograph.

Photo credit: Locomotive Firemen and Enginemen's Magazine - page 766 - December, 1913
Kelley Island Lime & Transport Co. #65 - s/n 2899
Built 02/17/1917 ~ 36" ~ 8" x 8" cylinders ~ 27½" drivers ~ 24 tons ~ 2 trucks

The locomotive operated on Kelley Island, Ohio
The photo is from the Robert W. Richardson collection
Kelley Island Lime & Transport Co. #67 - s/n 2901
Built 02/23/1917 - 36" - 8" x 8" cylinders - 27½" drivers - 24 tons - 2 trucks

The locomotive operated near the company's Marblehead, Ohio location.

Kelley Island Lime & Transport Co. #70 - s/n 2904
Built 03/10
/1917 - Std gauge - 8" x 8" cylinders - 27½" drivers - 24 tons - 2 trucks

The locomotive operated on Kelley Island, Ohio
The photo was published in The Lakeside and Marblehead Railroad
Kelley Island Lime & Transport Co. #71 - s/n 2917, #69 - s/n 2903, & #67 - s/n 2901
s/n 2917: Built 03/19/1917 - 36" gauge - 8" x 8" cylinders - 27½" drivers - 24 tons - 2 trucks
s/n 2903: Built 03/03/1917 - 36" gauge - 8" x 8" cylinders - 27½" drivers - 24 tons - 2 trucks
s/n 2901:
Built 02/23/1917 - 36" gauge - 8" x 8" cylinders - 27½" drivers - 24 tons - 2 trucks

Locomotives noted above in the same left to right order in which they are parked in the photo on July 3, 1938 at the company's roundhouse near Marblehead Ohio.  The locomotive at extreme right in the photo is unidentified.   It is interesting to note, the locomotives are still using "link and pin" coupling at this late a date.   Also, none of the four had headlights or airbrake hoses (at least on the front).

Photo Credit: Denver Public Library.     In the library's text for this photo, they incorrectly note the left most locomotive (#71) as #21.

Kelley Island Lime & Transport Co. #72 - s/n 2918
Built 03/19/1917 - 36" gauge - 8" x 8" cylinders -
27½" drivers - 24 tons - 2 trucks

The locomotive operated near Marblehead, Ohio.  The rear portion of Kelley Island Lime & Transport Co. #67 - s/n 2901 is seen at right in the photo.

Kelley Island Lime & Transport Co. #73 - s/n 2919 ~ destined for Marblehead, Ohio
Built 03/19/1917 ~ 36" gauge ~ 8" x 8" cylinders ~ 27½" drivers ~ 24 tons ~ 2 trucks

Photo credit: Bob Lorenz collection via The Lakeside and Marblehead Railroad
Kelley Island Lime & Transport Co. #74 - s/n 3218
Built 07/02
/1923 ~ 36" gauge ~ 8" x 8" cylinders ~ 29" drivers ~ 24 tons ~ 2 trucks

The locomotive operated on Kelley Island, Ohio
The photo was published in The Lakeside and Marblehead Railroad
Kelley Island Lime & Transport Co. #75 - s/n 3219 in 1938
Built 07/02/1923 - 36" gauge - 8" x 8" cylinders - 29" drivers - 24 tons - 2 trucks

The railroads base of operations was Marblehead, Ohio
Photo courtesy of the Marc Reusser collection.

Kelley Logging Co., Ltd. #1 - s/n 3344
Built 02/17/1930 ~ Std gauge ~ 13" x 15" cylinders ~ 36" drivers ~ 3 trucks ~  a Pacific Coast Shay

The locomotive operated near
Aero Camp (Morsby Island), British Columbia Canada.
The photo is part of the Taylor Rush Collection
Kenilworth & Helper Railroad Co. #100 - s/n 1967
Built 08/24/1907 ~ Std
gauge ~ 12" x 15" cylinders ~  36" drivers ~ 70 tons ~ 3 trucks

The locomotive, owned by the Independent Coal & Coke Co., operated near Kenilworth, Utah
The photo is from the Utah State Historical Society ~ Shipler Colllection ~ ID = 03209
Kenilworth & Helper Railroad Co. #151 - s/n 2703
Built 09/20/1913 - Std gauge -
14½" x 15" cylinders - 36" drivers - 90 tons - 3 trucks

The locomotive, owned by the Independent Coal & Coke Co., operated near Kenilworth, Utah
Photo hosted by Don Strack's UtahRails.net

Kentucky & Tennessee Railway #3 ~ s/n 1530 at the train depot in Stearns, Kentucky
Built 06/24/1905 ~ Std
gauge ~ 11" x 12" cylinders ~ 32" drivers ~ 45 tons ~ 2 trucks

The locomotive was owned by the
Stearns Coal & Lumber Co.
The photo is from the U.S. National Park Service Collection.
Kentucky, Rockcastle & Cumberland RR Co. #4 - s/n 2827
Built 02/25/1915 - Std gauge -
12" x 15" cylinders - 36" drivers - 70 tons - 3 trucks

The locomotive, owned by the Turkey Foot Lumber Co., operated near Cressmont, Kentucky.  It was named "Edwin".
The photo is from the Donald R. Hensley Jr. Collection
Kerbaugh, H. S. Inc. #100 -  s/n 717
Built 06/28
/1902 - Std. gauge - 11" x 12" cylinders - 33" drivers - 40 tons - 2 trucks

The photo was taken of the locomotive while on the Pennsylvania Railroad within the Manor Township of Lancaster County, Pennsylvania in 1905.
It is part of the Benjamin F. G. Kline, Jr. collection
Kerry Timber Company #21 - s/n 2864
Built 01/27/1917 - Std gauge - 10" x 12" cylinders - 29½" drivers - 45 tons - 2 trucks

The locomotive operated near Kerry, Oregon
The photo is part of the Clark Kinsey collection held at the University of Washington Library ~ PH Coll 516.1622
Kespine Lumber Co. #1 - s/n 3291 -  destined for Dorris, California
Built 10/28/1925 - Std. gauge - 11" x 12" cylinders - 33" drivers - 50 tons - 2 trucks

The company was affiliated with Topsy Lumber Company also of Dorris, California

Key Valley Railway #1 - s/n 2679
Built 06/09
/1913 - Std gauge - 11" x 12" cylinders - 32" drivers - 50 tons - 2 trucks

The locomotive, owned by Pakesley Lumber Co. Ltd., is pictured near Lost Channel, Ontario, Canada

Both photos hosted by Barry Cott of Station Studios.


Key Valley Railway #2 - s/n 2386
Built 10/13
/1910 - Std gauge - 8" x 10" cylinders - 27½" drivers - 28 tons - 2 trucks

The locomotive, owned by Pakesley Lumber Co. Ltd., operated near Lost Channel, Ontario, Canada
Both photos hosted by Barry Cott of Station Studios.

Kiernan Flora Logging Co. #501 - s/n 3068
Built 03/09/1920 - Std gauge -
11" x 12" cylinders - 32" drivers - 50 tons - 2 trucks

The locomotive operated near Kerry, Oregon.
The photo is part of the Clark Kinsey collection held at the University of Washington Library  ~ PH Coll 516.1189


King Family ~ s/n unknown
Built ?? ~ ??" gauge ~ ?? cylinders ~ ?? drivers ~ ?? tons ~ 2 trucks ~ Class A ~ vertical boiler

The locomotive operated near Saltillo, Texas.
The photos were published in East Texas Logging Railroads

Kinney, Robert C. Timber Co. #2 - s/n 2112
Built 11/30
/1908 ~ Std gauge ~ 11" x 12" cylinders ~ 32" drivers ~ 50 tons ~ 2 trucks

The locomotive operated near Kerry, Oregon.
The photo is from the Washington State Archives ~ John T. Labbe Collection ~ ID = AR255-114-0-1_L-1515_1

Kinzell Lumber Co. #5 - s/n 3186
Built 07/22/1922 ~ Std gauge ~ 11" x 12" cylinders ~ 32" drivers ~ 50 tons ~ 2 trucks

The locomotive
operated near New Wood, Wisconsin.
The lower photo is part of the Mattison Camera Shop collection held at the Central Wisconsin Digitization Project  ~  ID: P06-1-21
Kirby Lumber Co. #36 - s/n 804 @ Silsbee, Texas in 1939
Built 06/12/1903 - Std gauge - 10
" x 10" - 29½" drivers - 37 tons - 2 trucks

Photo courtesy of the Marc Reusser collection
Kirby Lumber Co. #39 - s/n 807 near Silsbee, Texas
Built 07/25/1903 - std gauge -
10" x 12" - 29½" drivers - 37 tons - 2 trucks

Photo courtesy of the Marc Reusser collection
Kirby Lumber Co. #49 -  s/n 1621 @ Voth, Texas on 11/30/1947
Built 12-22-1905 - Std.  gauge - 10" x 12" cylinders - 29½" drivers - 37 tons - 2 trucks

Photo by William Witbeck
Kirby Lumber Co. #51 - s/n 1709 - near Silsbee, Texas
Built 07/20/1906 - Std. gauge - 10" x 12" cylinders - 29½" drivers - 37 tons - 2 trucks


Kirby Lumber Co. #55 - s/n 2327 - near Silsbee, Texas
Built 05/28/1910 - Std. gauge - 10" x 12" cylinders - 29½" drivers - 42 tons - 2 trucks

Kirby Lumber Co. #56 - s/n 2328 Built 05/28/1910 ~ Std. gauge ~ 10 x 12" cylinders ~ 29½" drivers ~ 42 tons ~ 2 trucks

The locomotive operated near Silsbee, Texas.
The photo is from the Washington State Archives ~ John T. Labbe Collection ~ ID = AR255-114-0-1_L-1746
Kirby Lumber Co. #60 - s/n 2553
Built 07/08/1912 - Std gauge - 11" x 12" cylinders - 32" drivers - 50 tons - 2 trucks

The locomotive operated near Browndell, Texas.
The photo is part of the Lynnie Gibbs collection.
Kirby Lumber Co. #75 -  s/n 3063 - near Voth, Texas in October, 1950
Built 02/20/1920 - Std gauge -
10" x 12" cylinders - 29½" drivers - 42 tons - 2 trucks

Klickitat Logging & Lumber Co. #7- s/n 3346 @ Klickitat, Washington
Built 11/29/1929 - Std gauge - 13" x 15
" cylinders - 36" drivers - Pacific Coast Shay

The company was owned by the
St. Regis Paper Co.

Knight, A. W.  & Co. #2 - s/n 959
Built 11/10/1904 ~ Std gauge ~ 12
" x 12" cylinders ~ 36" drivers ~ 55 tons ~ 2 trucks

The locomotive operated near Maple Falls, Washington
The photos are from the
Washington State Archives ~ John T. Labbe Collection the following IDs:

top       ~
ID = AR255-114-0-1_L-0778
bottom ~ ID = AR255-114-0-1_LL-1727
Kolambugan Lumber & Development Co. #3 - s/n 3234
Built 09/26/1923 ~ 42" gauge ~ 11" x 12
" cylinders ~ 32" drivers ~ 50 tons ~ 2 trucks

The locomotive, owned by Millars Timber & Trading Co., operated near Kolambugan, Mindanao, Philippine Islands

Kolambugan Lumber & Development Co. #4  - s/n 3305
Built 07/26/1926 ~ 42" gauge ~ 11" x 12" cylinders ~ 32" drivers ~ 50 tons ~ 2 trucks

The locomotive, owned by Millars Timber & Trading Co., operated near Kolambugan, Mindanao, Philippine Islands

Koontz, Phillips & Stamm ~ s/n 398
Built 05/28/1892 ~ 36" gauge ~ (2)7" x 12" cylinders ~ 28" drivers ~ 13 tons ~ 2 trucks

The locomotive operated near Gladwin, West Virginia
Kosmos Timber Co. #3 - s/n 2845 near Kosmos, Washington on March 8, 1952
Built 11/24/1916 - Std gauge - 15" x 17
" cylinders - 40" drivers - 100 tons - 3 trucks

Koster Products Co. #5 s/n 1762
Built 10/26
/1906 ~ 36" gauge ~ 12" x 15" cylinders ~ 32" drivers ~ 65 tons ~ 3 trucks

The locomotive operated near Astoria, Oregon.
The photo is part of the James Nelson collection.

Koster Products Co. #6 -  s/n 2967
Built 03/18/1918 ~ Std. gauge ~ 10" x 12" ~ 29½" drivers ~ 42 tons ~ 2 trucks

The locomotive operated near Astoria, Oregon.
The photo is from the Washington State Archives ~ John T. Labbe Collection ~ ID = AR255-114-0-1_L-2144

1.Data and/or s/n provided courtesy of Dan Rowe of the Dripping Springs Locomotive Works

This is Shay Images Page - K

More Shay Image Pages:        New Images
Aa-Al | Am-Az | Ba-Bi | Bj-Bz | Ca-Cd | Ce-Cz | D | E | F | Ga-Gi | Gj-Gz | HIJ | KLMa-Mh | Mi-Mz | N | O | PQ | Ra-Rh | Ri-Rz Sa-Si | Sj-Sz | TUV | Wa-Wd | We | Wf-Wz | XYZ | Unknown|               Master List
   (Alpha by
operating entity name) - Click on the   s/n ####   for more data & other owners courtesy of ShayLocomotives.com
-

Home| Baldwin| Bell| Byers| Climax| Davenport| Dewey| Dunkirk| Heisler| Other| Rod| Shay| Willamette|
Books| Search| Videos|
 Help!



   We  Need  Your  Help!

 Page changed: February 12, 2024 03:37:39 PM
