Railway Appliance Research Ltd. #115 - s/n 3350 @ the yards of Vancouver Wharfs Ltd. in North Vancouver,  British Columbia, Canada - 03/1970
Built 04/04/1936 - Std. gauge - 13"x"15" cylinders - 36" drivers - 3 trucks - Pacific Coast model

Preserved
at Fort Steele Heritage Town, British Columbia, Canada
Photo from the Robert Turner collection.
Raine Lumber Co. #3 - s/n 3131 - destined for Honeydew, West Virginia
Built 10/23/1920 - Std. gauge - 12"x15" - 36" drivers - 70 tons - 3 trucks

Operational @ Cass Scenic Railroad State Park - Cass, West Virginia

Ranwood Lumber Co. #3 - s/n 2731
Built 03/15/1914 ~ 36" gauge ~ 8"x 8" cylinders ~ 27" drivers ~ 24 tons ~ 2 trucks

The locomotive, named "Boot Jack", operated near the company's Pickens, West Virginia.
Photo credit: West Virginia University Libraries

Rapides Lumber Co., Ltd. #3 - s/n 564 - circa 1904
Built 11/12/1898 - 36" - 9" x 8" cylinders -
26" drivers - 20 tons - 2 trucks

The locomotive operated near Woodworth, Louisiana.   Rapides was a subsidiary of Long-Bell Lumber Co.
Photo hosted by: Texas Transportation Archive

Rapides Lumber Co., Ltd. #5 - s/n 828 - circa 1904
Built 12/19/1903 - 36" gauge - 10" x 10" cylinders -
28" drivers - 33 tons - 2 trucks

The locomotive operated near Woodworth, Louisiana.   Rapides was a subsidiary of Long-Bell Lumber Co.
Photo hosted by: Texas Transportation Archive

Ray Lumber Co. #1 - s/n 2560
Built 08/21/
1912 - Std gauge - 10" x 10" cylinders - 29" drivers - 36 tons - 2 trucks

T
he locomotive operated near Ray, Maine

Rayonier Inc. #3 - s/n 2305 - Polson Museum, Hoquiam, Washington
Built 05/09/1910 - Std. gauge - 8"x8" cylinders - 27 drivers - 24 tons - 2 trucks
140d

Under restoration at  Mt. Rainier Scenic Railroad

Photo credit: Troyce Brooks collection

Rayonier Inc. #5 - s/n 2855 - near Sekiu, Washington
Built 06/10/1916 - Std. gauge -12"x15" cylinders - 36" drivers - 70 tons - 3 trucks


Rayonier Inc. #7 - s/n 3012 - Sekiu, Washington
Built 04/14/1919 - Std gauge - 12"x15" cylinders - 36" drivers - 70 tons - 3 trucks

Bud Laws collection
Rayonier Inc.  #10 - s/n 3348  @Tillicum Park  in Forks, Washington - preserved
Built 04/29/1930 - std. gauge - 13" x 15" cylinders - 36" dia. drivers

After being built for
stock by Lima in 1930,  it remained unsold for 11 years until finally purchased by Ozette Timber Company.  In 1945 it was purchased by Rayonier and later retired to Forks in 1959.

Photo provided courtesy of Uwe Doerflein of Cadolzburg, Germany
Data provided courtesy of Brian Fritz

Rayonier Inc. #15 - s/n 3318 @ Soho Camp in 1953
Built 04/08/1928 ~ Std. gauge ~ 13"x 15" cylinders ~ 36" drivers ~ 78 tons ~ 3 trucks ~ Pacific Coast model

The locomotive operated near the company's Sekiu, Washington location.
Rayonier Inc. #91 - s/n 3322 - Hoquiam, Washington
Built 11/15/1928 - Std gauge - 13"x15" cylinders - 36" drivers - 3 trucks - Pacific Coast model

Bud Laws collection
Red River Lumber Co. #300 - s/n 1840
Built 07/13/1907 - Std gauge - 17" x 18" cylinders - 46" drivers - 150 tons - 4 trucks

The locomotive operated near Westwood, California
The photo is part of the Mantin E. Hansen collection
Reed, H. W.  & Sons Construction Co. #1- s/n 2806
Built 09/22/1914 - 24" gauge -  6" x 10" cylinders - 22" drivers - 13 tons - 2 trucks

The locomotive operated at the company's Mishawaka, Indiana location.
Rheem Manufacturing Co. - s/n 3342
Built 09/27/1929 - 36" gauge - 10" x 10" cylinders - 29" drivers - 36 tons - 2  trucks

The locomotive operated at the company's Shipbuilding Division near Harbor Junction Wharf, Rhode Island.
It was converted to standard gauge prior to its acquisition by the company.
