Yawata (Yahata) Iron Works #48 - s/n 1868  - taken 1907 in the Fukuoka Prefecture*, Japan
Built 04/27/1907 - 42" gauge - (2) 6" x 10" cylinders - 22" drivers - 10 tons - 2 trucks

The locomotive was owned by the Imperial Government Steel Works
The photo is from the T.Matsumoto collection and was published in
The Genealogy of the Steam Locomotive" (Kikansha no Keifuzu) -  by Sigenobu Usui published 1973 by Koyusha

*A prefecture is a government district in Japan.

Yawata (Yahata) Iron Works #50 - s/n 1883
Built 04/27/1907 - 42" gauge -
(2) 6" x 10" cylinders - 22" drivers - 10 tons - 2 trucks

The locomotive, owned by the Imperial Government Steel Works, operated in the Fukuoka Prefecture, Japan


Yawkey Bissell Lumber Co. #142 - s/n 2784  - destined for White Lake, Wisconsin
Built 04/11/1917 - Std gauge - 10
" x 12"  cylinders - 30" drivers - 42 tons - 2 trucks

Yellow Pine Mining Co. #1 -  s/n 2500
Built 01/05/1912 - 36" gauge - (2) 8" x 12" cylinders - 26" drivers - 20 tons - 2 trucks

The locomotive operated near Jean, Nevada
The photo is part of the Ferron-Bracken Collection held at the University of Nevada @ Las Vegas ~ ID: pho013882

Yellow Pine Mining Co. #2 -  s/n 2793
Built 07/15/1916 - 36" gauge - (2) 8" x 12" cylinders - 26" drivers - 20 tons - 2 trucks

The locomotive operated near Jean, Nevada
Photo hosted by: University of Nevada @ Las Vegas

Yosemite Lumber Co. #1 - s/n 2524
Built 04/09/1912 - Std. - 10" x 12" cylinders - 29" drivers - 42 tons - 2 trucks

The locomotive operated near Merced Falls, California
Photo hosted by the Sierra Nevada Logging Museum

Yosemite Lumber Co. #2 - s/n 2660
Built 05/17/
1913 - Std gauge - 11" x 12" cylinders - 32" drivers - 60 tons - 3 trucks

The locomotive operated near Merced Falls, California
Photo hosted by the Sierra Nevada Logging Museum
Yosemite Lumber Co. #3 - s/n 2803 ~ destined for Merced Falls, California
Built 06/18/1915 ~ Std gauge ~ 12" x 15
" cylinders ~ 36" drivers ~ 70 tons ~ 3 trucks

Image credit: St. Louis Lumberman - page 96 - July 15, 1916

Yosemite Lumber Co. #4 - s/n 3092  - destined for Merced Falls, California
Built 07/07/1920 - Std. gauge - 12" x 15" cylinders  - 36" drivers - 70 tons - 3 trucks



Yosemite Mtn. & Sugar Pine Rwy #10 -  s/n 3315 - operational @ Fish Camp, California - taken Fall of 1997 -
Built 03/08/1928 - 36" gauge  - 12" x 15" cylinders  - 34" drivers - 70 tons - 3 trucks

Photo by and courtesy of Robert Weed of Birmingham, Michigan

Yosemite Mountain Sugar Pine RR #10 - s/n 3315 - Cylinders (top) - Truck Drive Gears (center) - Builder's Plate (bottom) - @  Fish Camp,  California -  operational - Photos by Walter Murphy
Yreka Western Railroad #94 -  s/n 2943 @ Yreka, California circa 1943-46
Built 10-04-1917 - Std.  gauge - 12" x 12" cylinders - 32"  drivers - 65 tons - 3 trucks



Zuni Mountain Railroad #3 - s/n 2321
Built 05/10/1910 - Std gauge -
12" x 15" cylinders - 36" drivers - 70 tons - 3 trucks

The railroad, owned by the American Lumber Company, was located near Thoreau, New Mexico

Photo credits:
John Bigley collection ~ Historical Society of New Mexico, Inc. ~ Zuni Mountain Railroads, Cibola National Forest, New Mexico


1.Data and/or s/n provided courtesy of Dan Rowe of the Dripping Springs Locomotive Works
