Saginaw & Manistee Lumber Co.  #1 - s/n 1481
Built 1917 ~ Std. gauge ~ 45 tons ~ 2 trucks ~ Class B 903

The locomotive operated near the company's Williams, Arizona location.

Saginaw Timber Co. #3 - s/n 1379 @ Brooklyn, Washington in 1938
Built 03-1916 - Std gauge - 70 tons - Class C
901d

This is the company's second of two Climaxes with the road number 3.
Saginaw Timber Co. #3 - s/n 1379 - destined for Aberdeen, Washington
Built 03-1916 - Std.  gauge - 70 tons - 3 trucks - Class C 903

Image credit: The Lumber Trade Journal ~ page 57 ~ October 15, 1916



Saint John & Ophir Railroad #1 - s/n 1159
Built 1912 - Std gauge - 85 tons - Class C

The locomotive operated near Ophir, Utah

Photo details:
~ top       : July 5, 1912 - hosted by the Utah Division of State History
~ middle : circa 1922 @ at St. John Station on the Oregon Short Line - hosted by the Utah Division of State History
~ bottom: The Salt Lake Mining Review - August 15, 1912 - page 13

An interesting addition likely made to the locomotive subsequent to its manufacture was the extension of rear cab roof to completely overhang  the fuel bunker.  This is seen in the middle photo.

The railroad owned two class "C" Climaxes, with the second being s/n 1189 Although the source text accompanying the middle photo notes the locomotive is SJORR #1, there is one notable difference this particular locomotive has when compared to the same features on locomotive in the top and bottom photos.  Both hand rails on either side of the cab entrance on the middle locomotive are significantly longer than the same on the other two photos.  Could the locomotive in this middle photo actually be s/n 1189?


Saldern Logging Co. #2 - s/n 190
Built 1899 - Std. gauge - 25 tons - 2 trucks - Class B 903

The locomotive operated near Grays River, Washington
Photos hosted by:

~ Upper : Old Oregon Photos
~ Lower : NERAIL North American Railroad Photo Archive

San Joaquin & Eastern RR #105 - s/n 1441 - Auberry, California
Built 1916-17 - Std gauge - 14 1/2" x 16" cylinders - 35" drivers - 70 tons - 3 trucks - 140,000 lbs. - 200 lb. boiler pressure. Purchased new by SJ&E on 12/13/1916 for $13,583.68 250
d



San Joaquin & Eastern RR  #109 - s/n 1627 - Auberry, California
Built 10/1922 - Std gauge - 70 tons - Class C - 3 Trucks
121d

Photo courtesy of the Marc Reusser collection.

Scottish Logging Co. #44 - s/n ? @ Nanaimo on Vancouver Island, British Columbia, Canada
Photo taken circa 1926

Source: H.W. Roozeboom - photographer  -  British Columbia Archives

Seattle Car Manufacturing Co. #101 - s/n 1067 - destined for Renton, Washington
Built 02-1911 - Std gauge - 20 tons - Class A 903d


Seattle Logging Co. #2 - s/n 242
Built 02-1901 ~ 36" gauge ~ 35 tons ~ 2 trucks ~ Class B

The locomotive operated near Port Crescent, Oregon
The photo is
part of the Bert Kellogg collection held at the Port Angeles Public Library, Washington Library  ~ RAILCLMX028

Seeboomook Lake & Saint John Railroad  #2 - s/n x108
Built 1906 - Std gauge - 45 tons - Class B

The locomotive, owned by the
Great Northern Paper Co., operated in northwestern Maine


Sequim Bay Logging Co. #890 - s/n 890 @ Sequim Bay near Blyn, Washington
Built 07-1908 - Std. gauge - 45 tons - 2 trucks - Class B 903

The locomotive was built with the smoke box door that was hinged to open to the left.  An unusual practice for Climax.
Photo Credit: Historic Photo Archive

Seward Peninsula Railroad #5 - s/n 670 ~ Near the Nome River, Nome, Alaska
Built 05-1906 ~ 36" gauge ~ 23 tons ~ 2 trucks ~ Class B

The photo is part of the Otto Daniel Goetz Collection at the Anchorage Museum of History and Art ~ Ref: AMRC-b01-41-380


Seward Peninsula Railroad #6 - s/n 672
Built 1906 ~ 36" gauge ~ 23 tons ~ 2 trucks ~ Class B

The locomotive operated near Nome, Alaska
The top photo is  part of the Alaska and Polar Regions Collection at the University of Alaska:  Photo ID:  UAF-1966-54-401

The lower photo is part of the Nowell Collection at the Alaska State Library:    Photo ID:  ASL-P48-044
Sewell Valley Railway #2 - s/n 1049 @ Rainelle, West Virginia
Built 09/1905 - Std. gauge - 75 tons - 3 trucks - Class C 903

Photo Credit: West Virginia University Libraries




Shanytown Rwy #1203 - s/n 1203  @ Shantytown -  Westland, New Zealand - operational
Built 1913 - 42" gauge - 30 tons - 2 trucks
120d

 Purchased by the Potate Timber Co., Matapuna NZ and shipped unassembled to New Zealand.  Assembled in the NZ Railways Petone workshops.   Later sold to Pukuwea Sawmills Ltd of Mananui, NZ where it continued to work after subsequent resale to Ellis & Burnard.  During the 1940's it was transferred to work in Mangapahei before its final commercial use as a yard shunter in Ongarue in 1962.    It was purchased for preservation in the mid 1960's and moved south to the current Shantytown site in Westland by 1969.  It began operation at Shantytown in January of 1980 where it continues its duties today.

Upper two photos - Jeffrey Harrison 1994
Lower two photos - Ian Tibbles 1990

Shawnigan Lake Lumber Co. Ltd. # 1 (1st) - s/n 335 - Shawnigan Lake, Vancouver Is., British Columbia, Canada
Built 7/1902 - 72" gauge - 15 tons - Class A - named "Betsy"
121d

This "tee" boilered engine used double flanged drivers  to navigate the company's "pole road" railroad.  The "rail" was actually de-limbed tree logs ("poles") laid end to end for track.

Identification by William Turner of the BC Forest Discovery Centre

sll-2-t.jpg (5519 bytes) Shawnigan Lake Lumber Co. Ltd. # 2 - s/n 1057 @  Duncan, British Columbia, Canada
Built 1910 - Std. gauge - 23 tons - 2 trucks
120d

Preserved at the B.C. Forest Discovery Center - Duncan, British Columbia, Canada
