Weaver Brothers Lumber Co. #1 -
s/n
342 ~ at left in expanded photo Built 03/19/1891 ~ 62" gauge ~ 9" x 12" cylinders ~ 29½" drivers ~ 20 tons ~ 2 trucks The locomotive operated near Flora, Louisiana As pictured, the locomotive had been previously converted to standard gauge. The photo is part of the Millspaugh Photograph collection held at Northwestern State University of Louisiana ~ with the ID: mp000135 |
|
Weaver Brothers Lumber Co. #2 -
s/n
988 ~ at right in expanded photo Built 03/10/1905 ~ Std gauge ~ 8" x 8" cylinders ~ 26½" drivers ~ 20 tons ~ 2 trucks The locomotive operated near Flora, Louisiana The photo is part of the Millspaugh Photograph collection held at Northwestern State University of Louisiana ~ with the ID: mp000135 |
|
Webb Logging & Timber Co. #9 -
s/n 3251 destined for Duckabush, Washington Built 02/15/1924 - Std gauge - 14½" x 15" cylinders - 36" drivers - 90 tons - 3 trucks |
|
Weber-King Lumber Co. #8 -
s/n 3136 - destined for Barham, Louisiana Built 11/11/1920 - Std. gauge - 11" x 12" cylinders - 32" drivers - 60 tons - 3 trucks140d |
|
Weed, James
B. & Co. #1 - s/n
147
- near Slate Run, Pennsylvania Built 04/07/1886 ~ 36" gauge ~ 10" x 10" cylinders ~ 28" drivers ~ 28 tons ~ 2 trucks The locomotive originally carried the #147
road number. It operated on the company's Slate Run
Railroad. |
|
Weed, James
B. & Co. #2 -
s/n 316 near Slate Run, Pennsylvania Built 11/29/1890 - 36" gauge - 10" x 12" - 29½" drivers - 32 tons - 2 trucks The locomotive operated on the company's Slate Run Railroad |
|
Weed, James
B. & Co.
#3 -
s/n 919
-
near Slate Run, Pennsylvania Built 09/09/1904 - 36" gauge - 10" x 10" cylinders - 28" drivers - 33 tons - 2 trucks140d The locomotive operated on the company's Slate Run Railroad |
|
|
Weed Lumber Co. #779 -
s/n
779 Built 11/19/1903 ~ Std gauge ~ 14½" x 12" cylinders ~ 36" drivers ~ 85 tons ~ 3 trucks The locomotive, owned by the Long-Bell Lumber Co., operated near Weed, California |
Weidman & Son Co. #1 -
s/n
2624 Built 11/22/1912 ~ Std gauge ~ 10" x 10" cylinders ~ 29" drivers ~ 36 tons ~ 2 trucks The locomotive operated near Trout Creek, Michigan |
|
Weidman & Son Lumber Co. #3 -
s/n
3220 - destined for Trout Creek, Michigan Built 06/12/1923 - Std gauge - 10" x 12" cylinders - 29½" drivers - 42 tons - 2 trucks |
|
Weist, Francis & Co. ~ s/n
854 Built 10/31/1903 ~ Std gauge ~ 11" x 12" cylinders ~ 32" drivers ~ 45 tons ~ 2 trucks On January 20, 1922, the locomotive derailed on a 600' long, 75' high trestle near Reliance, Oregon. The locomotive fell approximately 70'. Four company employees including company president, Francis M. Weist and one of his sons, ultimately lost their lives and an additional four were injured as a result of the accident. The locomotive was subsequently recovered, repaired, and ultimately served two subsequent owners until it's being scrapped on 11-28-1928. The image was published on page 14 of the March, 1922 issue of the Four L Bulletin a publication of the Loyal Legion of Loggers and Lumbermen (4 L) |
|
Welori Lumber Co. #2 -
s/n
1900 Built 05/14/1907 ~ Std gauge ~ 10" x 12" cylinders ~ 29½" drivers ~ 37 tons ~ 2 trucks The locomotive operated near Alden Bridge, Louisiana We thank George R. Kadelak for the identification of this locomotive. |
|
Westboro Lumber Co. #3 -
s/n 2546 - Westboro, Wisconsin Built 06/01/1912 - Std. gauge - 12" x 15" cylinders - 36" drivers - 70 tons - 3 trucks The locomotive operated on the company's Westboro & Northwestern Railway. |
|
Western Canada Power Co. #1 -
s/n
2066 Built 01/23/1908 ~ Std gauge - 10" x 12" cylinders - 29½" drivers - 42 tons - 2 trucks The locomotive operated
near Ruskin, British Columbia, Canada |
|
Western Forest Industries #4 -
s/n
3308 @ Honeymoon Bay, British Columbia, Canada in 1952 Built 02-26-1927 ~ Std. gauge ~ 11" x 12" cylinders ~ 32" drivers ~ 50 tons ~ 2 trucks Photo by William Witbeck |
|
Western Forest Industries #5 -
s/n 3320 - near Honeymoon Bay, British Columbia, Canada Built 07/26/1928 ~ Std gauge ~ 13" x 15" cylinders ~ 36" drivers ~ 3 trucks ~ a Pacific Coast Shay |
|
Western Indiana Gravel Co. #1 ~ s/n
3292 Built 1925 ~ Std gauge ~ 10" x 12" cylinders ~ 29½" drivers ~ 42 tons ~ 2 trucks The locomotive operated near Terre Haute, Indiana The photo is from the Washington State Archives ~ John T. Labbe Collection ~ ID= AR255-114-0-1_L-2813_1-2 |
|
Western Lumber Co. #2
-
s/n
3149
- destined for Milltown, Montana Built 11/29/1930 - Std gauge - 11" x 12" cylinders - 32" drivers - 60 tons - 3 trucks |
|
Western Maryland Railroad #4 -
s/n 2968 Built 05/20/1918 - Std gauge - 12" x 15" cylinders - 36" drivers - 70 tons - 3 trucks The locomotive operated in Elkins, West Virginia |
|
Western Maryland RR. #5 - s/n
2248 - @ Ridgeley, West Virginia - taken 9/2/1947 Built 04/26/1910 - Std. gauge - 17" x 18" cylinders - 46" drivers - 150 tons - 4 trucks140d Upper photo by Howard Davis.
Both from the Bud Laws collection
|
|
|
Western Maryland Railroad #6 -
s/n 3354 Built 5/14/1945 ~ Std. gauge ~ 17" x 18" cylinders ~ 48" drivers ~ 150 tons ~ 3 trucks ~ The last Shay built by Lima Locomotive Works The locomotive operated near Elkins, West Virginia Photo credits in order from top: 3rd ~ from the James Newhouse collection. 4th ~ photo is by Howard Davis from the Bud Laws collection |
Western Maryland RR #900 -
s/n 1609 Built 06/27/1906 - Std. gauge - 17" x 18" cylinders - 46" drivers - 150 tons - 4 trucks The locomotive, named "Maud", operated in the Elkins, West Virginia area. |
|
Western Pine Lumber Co. #1 -
s/n
2335 Built 06/06/1910 - Std gauge - (2) 6" x 10" cylinders - 22" drivers - 13 tons - 2 trucks
The locomotive operated near Klickitat, Oregon |
|
Western
Pine Lumber #5 -
s/n 3109 - destined for Klickitat, Washington Built 09/23/1920 - Std. gauge - 13½" x 15" cylinders - 36" drivers - 80 tons - 3 trucks |
|
West
Side Lumber Co. #5 - s/n
730
- in engine house at Tuolumne, California
- 1937 Built 09/16/1902 - 36" gauge - 12" x 12" cylinders - 32" drivers - 50 tons - 2 trucks |
|
West Side Lumber Co. #6 -
s/n 817 Built 12/01/1903 - 36" gauge - 12" x 12" cylinders - 32" drivers - 55 tons - 2 trucks The locomotive operated on the company's Hetch Hetchy & Yosemite Valley RR near Tuolumne, California |
|
West Side
Lumber Co. #9 -
s/n 3199 -
Tuolumne, California Built 04/23/1923 - 36" gauge - 12" x 15" cylinders - 34" drivers - 70 tons - 3 trucks The locomotive operated on the company's Hetch Hetchy & Yosemite Valley RR. Photo by John Cummins, courtesy of Ede Biro. |
|
West Side Lumber Co. #10 -
s/n 3315 near Tuolumne, California in October, 1961 Built 03/08/1928 - 36" gauge - 12" x 15" cylinders - 34" drivers - 70 tons - 3 trucks |
|
West Side Lumber Co. #12 -
s/n 3302 -
near Tuolumne, California in 1948 Built 04/21/1926 - 36" gauge -11"x 12" cylinders - 32" drivers - 60 tons - 3 trucks |
|
West Side
Lumber Co. #14 -
s/n 2835
@ Tuolumne, California on June 7,
1961 Built 06/15/1916 - 36" gauge - 11" x 12" cylinders - 32" drivers - 60 tons - 3 trucks Photo ©
1971 - Lyman E. Cox |
|
West Side Lumber Co. #15 -
s/n 2645 Built 05/20/1913 - 36"gauge - 11" x 12" cylinders - 32" drivers - 60 tons - 3 trucks Photo source: Bud Laws collection. |
|
West Side Lumber Co. #15 Co-drawn by and courtesy of Brad Johnson |
|
Weyerhaeuser Timber Co. #2 -
s/n 3090 @ Vail,
Washington Built 08/12/1920 - Std gauge - 13½" x 15" - 36" drivers - 80 tons - 3 trucks Photo courtesy of the Marc Reusser collection |
|
Weyerhaeuser Timber Co. #3 ~ s/n
2671 ~ at Vail, Washington Built 05/09/1913 ~ Std gauge ~ 12" x 12" cylinders ~ 36" drivers ~ 60 tons ~ 2 trucks The photo is part of the Clark Kinsey Collection at the University of Washington Library ~ ID = PH Coll 516.4942 |
|
Weyerhaeuser Timber Co. #5 -
s/n 3316
- at Vail, Washington Built 02-16-1928 - Std gauge - 13" x 15" cylinders - 36" drivers - 3 trucks - a Pacific Coast Shay Photo taken in 1941 |
1.Data and/or s/n provided courtesy of Dan Rowe of the Dripping Springs Locomotive Works
